Observation angle | 45°tilted |
Magnification of eyepiece | 16X |
Interpupillary distance | 50mm-80mm |
Diopter | ±5D |
Focal length of objective | F=300mm |
Magnification changer | 5-step: 0.4X, 0.66X, 1X, 1.5X, 2.5X |
Total Magnification | 2.7X, 4.4X, 6.6X, 10X, 16.6X |
Linear field | 90mm, 55mm, 37mm, 24mm, 15mm |
Fine focusing distance | 60mm |
Balance arm | / |
Illumination | Coaxial illumination with 10W LED lamp light source, brightness adjustable, illumination>30000lx |
Filter | Build-in green & blue filters |
Floor stand | Column height adjustable fitted on the 5-jaws round base with
casters
With beamsplitter and video camera adapter, C-mount 1/3 inch video camera attachable
|
Power supply | AC100V-AC240V |
Optional accessories | Demonstrator, Camera, SLR camera adapter, Monitor,
Objective (F=230mm & F=280mm). |
